Power Adapter
Categories
60W 12V 5A PC-120050
Model No:PC-120050Certification: ETL,CE,RoHS,FCC,CB,SAA,etc.
Ripple&Noise：<120Mvp
Product description: The external 60W 12V 5A switching power supply unit has universal AC input: 100-240V. This power adapter also have over temperature, over load, over current and short sircuit protection.
INQUIRY
12V 5A 60W AC DC Power Supply
Product Description:
Model No:PC-120050
AC input: 100-240Vac, 50/60HZ
DC voltage: 12V
Rated current: 5A
Rated power: 60W
Ripple & Noise: <120mVp-p
Efficiency:>88%
Voltage tolerance: ±5%
Line Regulation:±1%
Over Current protection: 130%-150%
Over Voltage protection: 115%-135%
Operation Temperature: -10-50℃ (±10℃)
Storage Temperature: -40-80℃ (±10℃)
DC connector: 5.5*2.5/2.1mm or 4Pin connector(Customized Available)
AC Power Cord: 0.8M/0.9/1.0M(Customized Available)
AC Power Cord: 1.2M AC Power Cable with UK/AU/USA/EU/India plugs
www.szpcsy.cn
Product Description:
Model No:PC-120050
AC input: 100-240Vac, 50/60HZ
DC voltage: 12V
Rated current: 5A
Rated power: 60W
Ripple & Noise: <120mVp-p
Efficiency:>88%
Voltage tolerance: ±5%
Line Regulation:±1%
Load Regulation: ±5%
Certification: ETL,CE,RoHS,FCC,CB,SAA,etc.
Over Current protection: 130%-150%
Over Voltage protection: 115%-135%
Operation Temperature: -10-50℃ (±10℃)
Storage Temperature: -40-80℃ (±10℃)
DC connector: 5.5*2.5/2.1mm or 4Pin connector(Customized Available)
AC Power Cord: 0.8M/0.9/1.0M(Customized Available)
AC Power Cord: 1.2M AC Power Cable with UK/AU/USA/EU/India plugs
This plastic shell of power adapter suit for this model:(All Optional)
| No.: | Model: | Output Voltage | Output Current | Output Power |
| 1 | PC-050070 | 5V | 6A | 30W |
| 2 | PC-050070 | 5V | 7A | 35W |
| 3 | PC-080050 | 8V | 5A | 40W |
| 4 | PC-120050 | 12V | 5A | 60W |
| 5 | PC-140045 | 14V | 4.5A | 60W |
| 6 | PC-160040 | 16V | 4A | 60W |
| 7 | PC-1850342 | 18.5V | 3.42A | 65W |
| 8 | PC-1900342 | 19V | 3.42A | 65W |
| 9 | PC2000325 | 20V | 3.25A | 65W |
| 10 | PC-240025 | 24V | 2.5A | 60W |
| 11 | PC-360015 | 36V | 1.5A | 60W |
| 12 | PC-4800125 | 48V | 1.25A | 60W |
